Description
VT07-B01 is a Linux-based video intercom which is an ideal solution for apartment and office buildings. VT07-B01 has a 7” LCD touch screen and provides various functions including audio and video intercom, support outdoor station and indoor monitor communication via TCP / IP, and it can control the main door release.
VT07-B01 can work with access control terminals to integrate access control function with video intercom. At the same time VT07-B01 is compatible with IP cameras and supports ONVIF protocol.
When visitors call-in via the access control terminal, VT07-B01 will automatically show 4 channel video display, including access control video and 3-way IPC videos at the same time. Users have a more detailed view of the outdoor environment.
VT07-B01 Specification
- OS: Linux System
- DDR: 2G
- Flash: 1G
- Display: 7“ LCD touch screen
- Resolution: 1024*768
- Video Display: Support 4 channel video display/ full screen
- Wired Network: Support RJ45 network port
- Wireless Network: IEEE 802.11b/ g/ n (optional)
- TF card slot: Support up to 128GB micro TF card
- Network Interface: RJ45 Network Port
- Power: DC 12V 2A
- Operating Temperature: -10°C to 55°C
- Dimension: 185*117*22 mm
- Weight: 410g
